Flipper Zero is a pretty handy hacking gadget both for new techies willing to start exploring things from scratch and professional penetration testers attempting to tap into varied digital resources for a number of reasons.  Overall, we can nicely say that this unique item can be very beneficial for varied cybersecurity professionals willing to breach into multiple electronic devices for several security reasons.

Book a Trial Demo Class

Training Available 24*7 Call at +91 9513805401

What is Flipper Zero and How Does it Work?

For tech nerds and practicing penetration testers, Flipper Zero is basically a lightweight multi-tool with a toy-like design.  In addition, it adores tapping and breaching into digital materials, incorporating hardware, access control systems, radio protocols, and many more.

Moreover, you can sincerely alter and enhance it whatever you wish because it is completely open-source.  As a result, give your tech skills an opportunity for development by experimenting with new techniques with the assistance of this exciting complete beginner hacking tool.

In addition to this, Flipper Zero is an extremely tiny piece of hardware with the curiosity of a cyber-dolphin.  When you utilize it, it grows and can interact with actual electronic systems.  Examine various access control, radio, and RFID technologies, and then utilize GPIO pins to debug hardware.  Flipper Zero is also made to assemble all the material resources needed for mobile research and development.

How Does it Work?

The all-exciting Flipper Zero has an integrated 433MHz antenna and a CC1101 chip, which makes it a powerful transceiver capable of up to 50 meters range.  I.e., It has a conceivable range of up to 50 meters for all the fantastic works it does for its master.

Flipper Zero Tech specs

Note the essential key factors from the viewpoints of a techie with the help of the following table:

MCU (Microcontroller unit)

Model: STM32WB55RG
ARM Cortex-M4 32-bit 64 MHz (application processor)
ARM Cortex-M0+ 32 MHz (network processor)
Flash: 1024 KB
SRAM: 256 KB

Display

LCD Monochrome
Resolution: 128×64 px
Controller: ST7565R
Interface: SPI
Diagonal Size: 1.4“

Battery

LiPo 2000 mA⋅h
7 days approximately

Sub-1 GHz module

Chip: TI CC1101
TX Power: 0 dBm max
Frequency bands (depends on your region):
● 315 MHz
● 433 MHz
● 868 MHz
● 915 MHz

NFC

Frequency: 13.56 MHz
Supported cards:
● ISO-14443A/B
● NXP Mifare® Classic®, Ultralight®, DESFire®, etc.
● FeliCa™
● NFC Forum protocols

RFID 125 kHz

Frequency: 125 kHz
Modulation: AM, PSK, FSK
Supported cards:
● EM400x, EM410x, EM420x
● HIDProx, Indala

GPIO

3.3 CMOS Level
Input 5V tolerant
Up to 20 mA per digital pin

Bluetooth LE 5.0

TX Power: 0 dBm max
RX Sensitivity: -96 dBm
Data rate: 2 Mbps

Micro SD

Up to 64GB MicroSDHC
Read/Write speed: up to 5 Mbit/s

Buzzer

Frequency: 100-2500 Hz
Sound Output: 87 dB
Type: Coin

Vibration Motor

Force value: 30 N
Speed: 13500 rpm

Infrared

TX/RX range: 800-950 nm
TX power: 300 mW

iButton 1-Wire

Operate modes: Reader/Writer/Emulator
Supported protocols:
● Dallas DS1990A
● CYFRAL

Control

5-button joystick
Back button
Reboot — Back+Left buttons for 2 seconds

USB

1x USB 2.0 port, type C
USB device
Charging

Physical

Size: 100 x 40 x 25 mm
Weight: 102 grams
Body materials: PC, ABS, PMMA
Operating temperature: 0 ~ 40 °C

Grab a Flat 10% Discount on Flipper Zero Buy!

Craw Security has brought you this fantastic offer where you can purchase Flipper Zero with a flat 10% discount.  Hence, grab this fascinating offer now!  Click Flipper Zero Buy to purchase this product now!
